250BPH 5 Gallon Bottle Washer With Checking Window

Ask Latest Price
Video Channel
Brand Name :FillPack
Model Number :BS-1
Certification :CE. ISO9001
Place of Origin :China,JiangSu,Zhangjiagang
MOQ :1
Price :USD $700/set
Payment Terms :L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :10 set / month
Delivery Time :15-20days after deposit receipt
Packaging Details :Wooden Case Package
Power :1.2KW
Weight :120kg
Material :SUS304
Automatic Grade :semi-auto
Capacity :200-250BPH
Packaging Type :Barrel
Condition :New
more
Contact Now

Add to Cart

Find Similar Videos
High Pressure 5 Gallon Bottle Washer Semi Auto Brush With Single Station 150BPH 00:44
High Pressure 5 Gallon Bottle Washer Semi Auto Brush With Single Station 150BPH
Cap Pulling 280BPH Five Gallon Bucket Washing Machine 01:31
Cap Pulling 280BPH Five Gallon Bucket Washing Machine
900*800*1200mm 18.9L Barrel Bottle Rinsing Machine 00:43
900*800*1200mm 18.9L Barrel Bottle Rinsing Machine
One Decapping Station SS304 5 Gallon Bottle Washer 00:38
One Decapping Station SS304 5 Gallon Bottle Washer
450BPH 5 Gallon Bottle Washing Machine 00:40
450BPH 5 Gallon Bottle Washing Machine
Emergency Stop Button SUS304 5 Gallon Bottle Washing Machine 01:54
Emergency Stop Button SUS304 5 Gallon Bottle Washing Machine
300BPH Pure Water 2 Heads ISO 5 Gallon Bottle Washer 00:54
300BPH Pure Water 2 Heads ISO 5 Gallon Bottle Washer
Linear Busher 450BPH 5 Gallon Washing Machine 01:07
Linear Busher 450BPH 5 Gallon Washing Machine
Full Set Complete Mineral Water Bottling Filling Line Automatic PET Plastic 00:45
Full Set Complete Mineral Water Bottling Filling Line Automatic PET Plastic
View Product Description

Description of BS-1 semi automatic Gallon washer decapping with checking window

Principle of this Gallon washer:

This machine is mainly use for washing the recycle empty 3-5gallon barrels in the 5 gallon barreled water filling line, it is for clean the impurity,deposition and algae etc,it also equipts decapping device.

Worker put used jar in right side of de-capper position, with the neck inserting into the hole, worker foot press pedal to release cap off neck; And then worker need to take the jar to insert into left side of the machine-washing position. After the jar putting in, the window need to be closed. Then the washer will be started by itself. During washing, the inner brush inside jar and Washing time is pre-settled, the machine will stop when time finish. Heating function could be switched on/ off as client’s needing.

Main Technical parameter of this Gallon washer:

Capacity 200-250b/h
Brushes 8
Barrel size 3-5gallon(270×490×56)
Air pressure 0.5MPa
Water consumption 0.01t/h
Power 1.12KW without heating, 2.12KW with heating
Outline dimensions 800*750*1200mm
Weight 120Kg

The details of this Gallon washer:

250BPH 5 Gallon Bottle Washer With Checking Window

250BPH 5 Gallon Bottle Washer With Checking Window

Our Services

we have an engineers team with high sense of responsibility and technology to do designing and commissioning for your equipments.

Each project was tracked together by special salesman and engineer in our company.

We provide one year warranty with spare parts free of charge.

Our engineer will go to your site to do installation and commissioning as the equipments are there and the water and electricity are ready.
